Retsch Vibratory Sieve Shaker AS 200 control Retsch Sieve NEW PRODUCT
Particle Size Analysis >> Retsch Vibratory Sieve Shaker AS 200 control Retsch Sieve NEW PRODUCT
Retsch Vibratory Sieve Shaker AS 200 control Retsch Sieve NEW
"The analytical sieve shakers of the series AS 200 are used in research & development, quality control of raw materials, interim and finished products as well as in production monitoring. The controllable electromagnetic drive offers an optimal adaption for every product. Sharp fractions are obtained even after very short sieving times.
With its all-digital controls, up to 99 sieving programs and calibration certificate the sieve shaker AS 200 control is indispensable for all users who attach importance to precision and operational convenience and need to comply with the guidelines of the ISO 9001." (RETSCH)
Application Examples:
cement clinker, chemicals, coffee, construction materials, fertilizers, fillers, flours, grains, metals powders, minerals, nuts, plastics, sand, seeds, soils, washing powder, ... continue to application database
Product Advantages:
NEW: up to 99 sieving programs
NEW: low noise operation thanks to optimized control
NEW: USB connection for use of EasySieve software
suitable for dry and wet sieving
excellent separation efficiency even with short sieving times
efficient electromagnetic drive
3-D throwing motion which ensures optimum use of the open sieve area and lets the sample move equally over the whole sieving surface
setting of sieve acceleration "g" for comparable and reproducible sieving results worldwide
sieve stack up to 550 mm height
free digital adjustment of all process parameters (time, amplitude or sieve acceleration, interval)
interval operation
optional sieve software EasySieve for control of the shaker, easy evaluation and documentation of results
fulfils all criteria for measuring equipment related to ISO 9001
calibration certificate
easy operation, ergonomic design
maintenance-free
Features
| Applications | separation, fractioning, particle size determination |
| Field of application | agriculture, biology, chemistry / plastics, construction materials, engineering / electronics, environment / recycling, food, geology / metallurgy, glass / ceramics, medicine / pharmaceuticals |
| Feed material | powders, bulk materials, suspensions |
| Measuring range* | 20 µm - 25 mm |
| Sieving motion | throwing motion with angular momentum |
| Max. batch / feed capacity | 3 kg |
| Max. number of fractions | 11 / 23 |
| Max. mass of sieve stack | 6 kg |
| Amplitude | digital, 0.2 - 3 mm |
| Controlled amplitude | yes |
| Sieve acceleration | 1.0 - 15.1 g |
| Time display | digital, 1 - 99 min |
| Interval operation | 1 - 99 s |
| Storable SOPs | 99 |
| Suitable for dry sieving | yes |
| Suitable for wet sieving | yes |
| USB interface | yes |
| Including test certificate / can be calibrated | yes |
| Suitable sieve diameters | 100 mm / 150 mm / 200 mm / 203 mm (8") |
| Max. height of sieve stack | 550 mm |
| Clamping devices | "standard", "comfort", each for wet and dry sieving |
| Protection code | IP 54 / IP 20 |
| Electrical supply data | 100-240 V, 50/60 Hz |
| Power connection | 1-phase |
| W x H x D | 417 x 212 x 384 mm |
| Net weight | ~ 35 kg |
| Standards | CE |
Please note:
*depending on feed material and instrument configuration/settings
"All sieve shakers of the series AS 200 work with an electromagnetic drive that is patented by RETSCH (EP 0642844). This drive produces a 3D throwing motion that moves the product to be sieved equally over the whole sieving surface. The advantage: high stress capacity, extremely smooth operation and short sieving times with high separation efficiency." (RETSCH)
For additional details regarding this equipment, please visit http://www.retsch.com/products/sieving/sieve-shakers/as-200-control/ to download the product brochure and data sheet.
